Quasar-C+ Relay Test Set: Powerful Current-Focused Secondary Injection Test Set with Configurable Voltage Output

Looking for a powerful and flexible relay test set for protection relay testing, secondary injection testing, IEC 61850 applications, and GOOSE-based digital substation schemes? The Quasar-C+ Smart Relay Tester is designed for professionals who need the full current output capability of the Quasar platform, combined with a highly flexible configurable voltage channel.

The Quasar-C+ relay tester includes the same dedicated current sources as the Quasar, making it an excellent solution for overcurrent, differential, distance, and protection relay testing applications where strong current injection capability is essential. In addition, it includes one configurable voltage output, V4, which can operate as a fully programmable voltage channel or as a flexible auxiliary output for AC voltage, DC voltage, current output, or battery simulation.

Industrial Grade Protective Relay Test Set

The Quasar-C+ is an industrial-grade secondary injection test set designed for testing conventional and IEC 61850 protection relays in substations, power plants, industrial facilities, and maintenance environments.

It provides the same current output capability as the Quasar, while incorporating one fully configurable voltage output channel, V4. This channel can be configured as 1 x 300 Vac, 1 x 5 A, 1 x 300 Vdc, or as a battery simulator with selectable 48, 125, or 250 Vdc levels.

This makes the Quasar-C+ a powerful and practical relay tester for applications where three-phase current injection is the main requirement, but where a flexible voltage, DC supply, or battery simulation channel is also needed.

Why Choose the Quasar-C+ Relay Tester?

• Full Current Output Capability: The Quasar-C+ includes the same dedicated current sources as the Quasar, providing powerful current injection capability for demanding protection relay testing applications.
• Configurable V4 Voltage Output: The V4 output can operate as a fully configurable voltage channel, offering high flexibility for secondary injection testing and protection relay validation.
• Multiple V4 Operating Modes: The V4 channel can be configured as 1 x 300 Vac, 1 x 5 A, 1 x 300 Vdc, or as a battery simulator with 48, 125, or 250 Vdc output.
• Secondary Injection Test Set for Current-Based Protection: The Quasar-C+ is especially suitable for overcurrent, differential, earth fault, breaker failure, and other protection functions where accurate current injection is essential.
• IEC 61850 and GOOSE Testing: The Quasar-C+ supports IEC 61850 and GOOSE-based testing, making it suitable for modern digital substation applications and communication-based protection schemes.
• Flexible Battery Simulation: The configurable V4 channel can be used as a battery simulator with selectable 48, 125, or 250 Vdc levels, allowing users to simulate common substation DC auxiliary supply voltages.
• Relay Testing Software: The Quasar-C+ works with intuitive relay testing software for manual, automated, and preconfigured tests, helping users reduce testing time and improve repeatability.
• Multiple Connection Modes: The Quasar-C+ supports convenient connection options for field, substation, and laboratory environments.
• Rugged and Portable Design: Built for field use, the Quasar-C+ is designed for professionals who need reliable relay testing equipment in demanding environments.

Configurable V4 Output for Maximum Flexibility

One of the key features of the Quasar-C+ relay test set is its configurable V4 output. Unlike conventional current-focused relay testers, the Quasar-C+ gives users an additional flexible channel that can be adapted to different testing needs.

• 1 x 300 Vac for AC voltage injection and protection relay testing.
• 1 x 5 A for additional current injection when required.
• 1 x 300 Vdc for DC voltage testing applications.
• Battery simulator with selectable 48, 125, or 250 Vdc output levels.

This flexible output makes the Quasar-C+ a practical secondary injection test set for users who need strong current outputs and one versatile voltage or DC auxiliary channel.

Applications of the Quasar-C+ Secondary Injection Test Set

The Quasar-C+ secondary injection test set is suitable for a wide range of protection relay testing applications, including:

• Overcurrent relay testing
• Differential relay testing
• Earth fault protection testing
• Distance relay testing with current-focused applications
• Breaker failure protection testing
• IEC 61850 relay testing
• GOOSE message testing
• Digital substation testing
• Substation DC battery simulation
• Commissioning and routine maintenance testing
• Fault analysis and troubleshooting
• Validation of protection relay settings

Relay Testing Equipment for Utilities, Industry and Maintenance Companies

The Quasar-C+ is designed for professionals who need reliable relay testing equipment with strong current output capability and a flexible auxiliary voltage channel. It is especially suitable for:

• Transmission and distribution utilities
• Power generation companies
• Industrial facilities with electrical substations
• Electrical maintenance companies
• Substation commissioning teams
• EPC contractors
• Protection and control engineers
• Relay manufacturers and testing laboratories

Powerful Current Injection with a Flexible Voltage Channel

The Quasar-C+ Smart Relay Tester is a powerful relay test set and secondary injection test set for users who need the current output performance of the Quasar platform, combined with one flexible and fully configurable voltage channel.

With its dedicated current sources, configurable V4 output, IEC 61850 and GOOSE testing capability, battery simulation function, and intuitive relay testing software, the Quasar-C+ is an efficient and versatile solution for modern protection relay testing.

Discover the Quasar-C+ Relay Test Set today and improve the efficiency of your current-based protection relay testing, secondary injection testing, IEC 61850 testing, and substation maintenance applications.

Upgradeable to Full Quasar Configuration

The Quasar-C+ is designed as a scalable version of the Quasar platform. It includes the same dedicated current sources as the Quasar and one configurable V4 voltage output as standard.

If full four-channel voltage capability is required in the future, the Quasar-C+ can be upgraded to a complete Quasar configuration by replacing the default voltage amplifier, which includes one voltage output, with the standard Quasar voltage amplifier offering four voltage outputs.

This upgrade can be performed at any time by purchasing the standard voltage amplifier module, allowing users to expand their relay test set without replacing the complete equipment.
